Custom Gable Boxes

A gable box is a folding carton whose top panels fold up into a carry handle. The pack needs no bag around it, which is why it turns up at events, weddings and takeout counters.

It ships flat, squares up in one movement and closes by hand in a couple of seconds. That combination of speed and a built in handle is what this structure is really for.

Get Custom Quote


Gable box specifications

Custom gable boxes specification sheet
Specification Detail
Box styleGable top with an integrated board handle.
Board300 to 350 GSM SBS for favors. 350 to 400 GSM for larger or food boxes. 350 GSM kraft.
Weight limitKeep packed weight under about two pounds so the handle crease holds.
SizingInternal length by width by depth. Quote usable internal height, not the arched height.
Food useFood grade board. Grease resistant coating where contents are hot or oily.
Window optionPET patch window on the front or side panel.
Base optionTuck base as standard. Locked base on heavier fills.
Printing and finishesDigital or offset. Gloss, matte, soft touch, spot UV, hot foil.
Minimum order100 boxes per size and per design.
Production time8 to 12 business days after dieline approval.
SamplesA plain structural sample takes 3 to 5 working days and a printed sample takes 7 to 10.
PricingNo setup or tooling charge. Break at 1,000 units.
Artwork and designAI, EPS or PDF on our dieline. Design support free at every stage.
ShippingFree shipping worldwide on all orders.

Everything about custom gable boxes

How the handle is formed

The top of the carton is cut as two arched panels that meet in the middle. When you fold them together the arches interlock and form a handle so the closure and the carry point are the same piece of board.

That is also where the limit sits. The handle is board rather than rope or plastic so it carries the weight of the contents through a single crease. We size the arch and the crease from the packed weight you tell us. Weight matters more on this style than on a standard carton.

Keep the packed weight under about two pounds on a gable box. Above that the handle starts to tear at the crease and a rigid handle box or a tote with a rope handle is the better structure. You will find both among our other custom styles.

Board and sizing

Use 300 to 350 GSM SBS on a small favor box and 350 to 400 GSM once the box gets larger or carries food. Uncoated kraft runs about 350 GSM and it is the common choice for a natural look at an event.

Give us internal dimensions in length by width by depth order. On a gable box the height you see includes the arched top. Tell us the usable internal height rather than the overall height, otherwise the pack comes back shorter inside than you expected.

Common sizes run from about 100 by 100 by 100 mm for favors up to about 200 by 150 by 180 mm for a takeout meal. We cut any size in between on a new dieline at no tooling charge, the same as on all our packaging boxes.

Food service versions

A gable box used for food needs food grade board and it usually needs grease resistance as well. We quote a grease resistant coated board where the contents are hot or oily and a plain coated board where the food is wrapped or dry.

Tell us what is going inside and whether it touches the board directly. That answer decides the material rather than the style and it is the one detail buyers leave out most often.

A window on the front panel lets the customer see the contents. On a food box the window normally takes a clear PET patch so nothing escapes and it should sit away from the crease lines.

Printing and finishes

Flat paperboard prints well so a gable box carries full color artwork on every panel including the arched top. Digital printing suits short runs and event work where several designs run together at the same unit price. Offset takes over above about 1,000 units and holds a named Pantone spot color exactly.

Gloss or matte lamination protects the print and it also protects the handle crease from splitting when the box is carried in the rain. Soft touch lamination suits gifting work. Hot foil on the front panel is the cheapest way to make an event box look expensive.

One thing to plan for is that lamination on a food box has to stay on the outside face where the contents do not touch it.

Structural options

A PET window on the front or the side shows the product. A hang tag hole through the handle carries a thank you card or a name tag and it is a die change rather than an added component.

A folded paperboard insert divides the inside for a set of small items. On heavier gable boxes we can add a locked base rather than a tuck base, which stops the bottom dropping when somebody lifts the box by the handle.

What your artwork has to hold

Send artwork as an AI, EPS or PDF file set on our dieline in CMYK at 300 dpi with 3 mm of bleed. Design support is free at every stage so we will fix a file that is not print ready rather than send it back.

Two limits apply whatever you choose. Keep positive type at 6 pt or larger and reversed type at 8 pt or larger because ink spreads slightly on board and fine reversed type fills in. Keep every line weight at 0.25 pt or above for the same reason.

Ordering and lead times

The minimum is 100 boxes per size and per design. Each size needs its own die so two sizes on one artwork counts as two minimums. There is no setup or tooling charge on the first order or on any reorder and the price break lands at 1,000 units.

Production runs 8 to 12 business days after you approve the dieline. A plain structural sample takes 3 to 5 working days and a printed sample takes 7 to 10. Shipping is free worldwide on every order.

Email Sales@boxesexpert.com with your dimensions and quantity and we will send a dieline, a 3D mockup and a price.

How To Get Started

Creating custom boxes is now easy with us. See how our process works.

Consultation

Send your product size, quantity and deadline. Not sure which board or style fits? Tell us what goes inside and we will specify it for you, then quote within 24 hours.

Design

Upload your artwork and our team will refine it to perfection. No artwork? No problem. Just tell us about your product and we will turn your ideas into beautifully designed packaging.

Proof

Nothing reaches the press until you approve it. You get a digital proof as standard and a physical sample on request, so you can check everything yourself before the full run.

Delivery

After production, every box goes through our strict quality control process to ensure it meets our standards. Once approved, your packaging is carefully prepared and delivered free to your own doorstep.

Frequently Asked Questions

What buyers ask before ordering custom gable boxes: how much the handle carries, board grades, food safe options, sizing and minimum quantities.

A gable box is a folding carton whose top panels fold up and interlock into a carry handle. The closure and the handle are the same piece of board, so the pack needs no bag around it.
Keep the packed weight under about two pounds. The handle is board rather than rope, so the load passes through a single crease, and above that weight the crease starts to tear. Heavier contents need a different structure.
Use 300 to 350 GSM SBS for a small favor box and 350 to 400 GSM once the box gets larger or carries food. Uncoated kraft runs about 350 GSM and it suits a natural look at an event.
Yes, on food grade board. Where the contents are hot or oily we quote a grease resistant coated board. Tell us whether the food touches the board directly, because that answer decides the material.
Common sizes run from about 100 by 100 by 100 mm for favors up to about 200 by 150 by 180 mm for a takeout meal. We cut any size in between on a new dieline with no tooling charge.
Yes. A window on the front or side panel normally takes a clear PET patch on food work so nothing escapes. Keep the window away from the crease lines so the panel keeps its stiffness.
The minimum is 100 boxes per size and per design. Each size needs its own die, so two sizes on one artwork counts as two minimums rather than one order of 200.
Production runs 8 to 12 business days after you approve the dieline. A plain structural sample takes 3 to 5 working days and a printed sample takes 7 to 10, which is worth ordering so you can test the handle with your own contents.
